三葉羅茨風機
2022-06-28
三葉羅茨風機是一種雙葉輪同步壓縮機械，每個三葉型轉子用兩個軸承支承，利用一對同步齒輪，使兩個轉子的相對 位置始終保持不變。屬容積式鼓風機，具有強制輸氣特征。三葉羅茨風機作為回轉式機械，具有比較穩定的工作特性， 三葉羅茨風機轉子與轉子、轉子與泵體｀轉子與側蓋之間都有微小間隙，因而工作腔內沒有摩擦，無接觸磨損部分，三葉羅茨風機經濟耐用，無需潤淆，使用壽命長，動力平衡性好．運轉一周有六次吸排氣過程，容積效率離結構簡單，使用維護方便 不需要內部潤滑，輸送的介質不含油等特點。泵轉子的支承采用了可靠的消隙結構，轉動部件作細致的動平衡，并采用高精度的斜齒輪，因此，運行平穩，噪聲低，使用更加可靠，可在商壓差下長期運行． 羅茨風機廣泛應用于陶盜、建材、造紙、電業、石油、化工、紡織、水產養殖、污水處理、食品等行業的氣力輸送系統． The three-lobe Roots blower is a two- impeller synchronous compressionmachine . Each three-bladed rotor 1s supported by two bearings. A pair of synchronous gears are used to keep the relative positions of the two rotors constant. It is a positive displacement blower with forced gas transmission chara cteristics As a rotary machine, the three-leaf Roots blower has relatively stable working characteristics. There is a slight gap between the rotor and rotor of the three-lobe Roots blower, the rotor and the pump body, and the rotor and the side cover. Therefore, there is no friction in the working chamber. contact with the wear part; the three-leaf Roots blowe is economical and durable,requires no lubrication, has a long service life and good dynamic balance. There are six suction and exhaust processes in one week of operation. The volumetric efficiency is high, the structure is simple, the use and maintenance are convenient, no internal lubrication is required, and the medium to be transported does not contain 0il.. The support of the pump rotor adopts a reliable anti-backlash structure, the rotating parts are carefully balanced, and the high-precision helical gear is used There fore, the operation is stable, the noise is low, the use is more reliable, and the long-term operation can be performed under the high pressure difference. Roots blowers are widely used in the pneumatic conveying systems of ceramics,building materials, paper, electricity, petroleum,chemical, textile, aquaculture, sewage treatment,food and other industries.
|
